UNIMUX-USBV-8UO KVM Switch (Front & Back)
NTI USB KVM SWITCH
| |
|
|
Buy Online
|
|
|
CONTROL UP TO 32 USB COMPUTERS WITH ONE USB KEYBOARD, USB MOUSE & VGA MONITOR | Features & Applications | The UNIMUX-USBV-xU USB KVM switch allows a user to control up to 32 USB computers with one USB keyboard, USB mouse and VGA monitor. Dedicated internal microprocessors emulate keyboard & mouse presence to each attached CPU 100% of the time so all computers boot error-free.- Features NTI's patented true autoboot USB switching - all attached USB PCs, MACs and SUNs can be booted simultaneously. Other USB KVM Switches on the market require individual, sequential boot-up.
- Compatible with USB-enabled PCs.
- Compatible with SUN Blade 100, SUN 1000, SUN Ray, SUN Fire(tm) 280R, and other USB-enabled SUN computers.
- Compatible with MAC G3/G4s. Supports MAC soft (keyboard) power-on.
- Crisp & clear 1900x1200 video resolution.
- Fully compliant with (1.0, 1.1) USB standards.
- USB SUN start-up keys are supported.
- SUN extra keys are emulated on USB keyboards with Windows keyboard layouts.
|
Hosts - Female USB Type B connector.
- SUN Blade 100, 1000, SUN Ray & SUN Fire(tm) 280R.
- PCs with USB-enabled OS (Win 98/2000) and USB ports.
- PCs with USB-enabled BIOS (legacy USB support) and USB ports.
- Supports any MAC with OS 8/9 and USB ports.
Keyboard - Female USB Type A connector.
- Compatible with most USB keyboards.
- Keyboard & mouse are hot-pluggable.
| Monitor - Crisp & clear 1900x1200 resolution.
- Female 15 pin HD connectors.
- A multiscan VGA monitor is required to display the different video outputs from different platforms.
- Bandwidth is 150 MHz.
Mouse - Female USB Type A connector.
- Compatible with most USB mice, including USB IntelliMouse®.
Power - 110 or 220 VAC at 50 or 60 Hz. via AC Adapter.
|
Keyboard - Use the keyboard to command the switch box to select ports or configure the SCAN delay.
| Optional-sold separately
- (OSD) On Screen Display
- Rackmount Option
2 port USB KVM switch
allows one user to access two USB CPUs with only one USB keyboard, USB mouse and VGA monitor Universal USB KVM switch
For use with Legacy Keyboard & Mouse
|
| AVAILABLE SIZES | NTI
Part # | # of
CPUs | Size (In.) WxDxH | Rack Units | Rack Size
(In.) WxDxH | UNIMUX-USBV-2U | 2 | 10x7.5x3.6 | 1RU | 19x10x1.75 | UNIMUX-USBV-4U | 4 | 10x7.5x3.3 | 1RU | 19x12x1.75 | UNIMUX-USBV-8U | 8 | 10x7.5x3.3 | 1RU | 19x12x1.75 | UNIMUX-USBV-12U | 12 | N/A | 3RU | 19x10x5.25 | UNIMUX-USBV-16U | 16 | 3RU | 19x10x5.25 | UNIMUX-USBV-24U | 24 | 3RU | 19x10x5.25 | UNIMUX-USBV-32U | 32 | 5RU | 19x10x8.75 |
|
