Minicom
MVS Multimedia Video Scaler: Broadcast
composite video onto computer video screens
The Minicom MVS Multimedia Video Scaler allows you to watch TV or video
on any PC monitor with a VGA input without installing any software.
The Minicom MVS Multimedia Video Scaler works by converting composite video and YC to PC VGA/SVGA
thereby allowing the broadcast of both video and audio from a video
source like a TV, VCR, DVD or camcorder to any standard computer
monitor and speakers.

Minicom MVS Multimedia Video Scaler
(rear view)
In the A/V field use the Minicom MVS Multimedia Video Scaler to scale any composite video source
into SVGA computer video signals for display with any standard
computer video extenders, splitters or broadcasters. This includes
Minicom's new CAT5 VDT, CAT5 AV Splitter and CAT5 VDS. Now live action
video can broadcast directly to patrons in airports, bus stations,
banks, conference rooms, department stores, restaurants, etc.

Minicom MVS
Multimedia Video Scaler Downloads & Manuals
|
Minicom MVS Multimedia Video Scaler
Specifications |
Cables & Connectors
|
CPU Input |
Screen In |
HDD15M |
| |
Audio In |
Jack |
| Video Input |
Video |
RCA |
| |
S. Video |
4P |
| |
Audio (R, L) |
2xRCA |
| Output |
Screen Out |
HDD15F |
| |
Audio Out |
Jack |
Resolution
|
PAL: 800x600x50hz
NTSC: 640x480x60hz |
| Power |
External Power
Adapter 6VDC |
| Warranty |
3 Years |
| Dimensions |
26Hx74Dx218Wmm/1.02Hx2.91Dx8.58W" |
| Weight |
0.5Kg |
| Shipping Weight |
1.3Kg |
| Operating Temp |
0°C to 40°C/32° F to
104°F |
| Storage Temp |
-40°C to 40°C/-40° F
to 104°F |
|
Minicom MVS Multimedia Video Scaler
Ordering Information |
| Multimedia Video Scaler (MVS) |
0CL61031 |
