Avocent CPS810
The 8-port Avocent CPS810 appliance delivers secure serial
over IP access to console ports of servers and serially
managed devices such as power management systems, network
hubs and routers.
Console port server features such as offline history
buffering and hardware break suppression distinguish the
Avocent CPS appliance from simplistic terminal servers,
which are often misused for this purpose.
Avocent CPS810 Features and Benefits
CPS units, and attached devices, can be centrally managed
using Avocent DSView 3 software. They can also be accessed
in a stand-alone manner using third-party software or Avocent
vConsole management software. These methods are designed
to meet the needs of data centers of all sizes.
The CPS serial over IP appliance is also available in
a 16-port model.
Large Data Center Application
In large data centers, the CPS serial over IP appliance
may be configured to work in unison with the DSR, SPC and
other Avocent switches and appliances. When attached to
the KVM, serial and power ports of devices within a data
center, the Avocent appliances enable administrators to
manage those devices through local access at the rack or
by remote access via KVM over IP connections.
Small to Mid-sized Data Center Application
For small to mid-sized data centers, the CPS unit may be
configured for stand-alone operation. In this mode, the
CPS serial over IP solution can be used in conjunction with
third-party Telnet and/or SSH client software for secure
console port management. User accounts and permissions may
be stored within the CPS unit or on an external RADIUS server.
Avocent CPS810 Software Features
- Complete KVM, Serial and Power Management Solution:
Works in unison with the DSR, SPC and other Avocent
appliances to enable administrators to manage a wide
range of data center devices through local access at
the rack or by remote access through KVM over IP connections.
- Centralized Management: Avocent DS management
software coordinates remote access to DS appliances,
and attached devices, in a centralized manner. The software
suite consists of the DSView software client; the DSAuth
central authentication, access control, audit server,
and administration for DS user accounts and appliances.
DSWebview provides browser-based users with a secure
gateway into the DS environment. Avocent DS management
software is sold separately.
- Security: The CPS appliance offers internal
and external user authentication methods and port-specific
access rights.
- Ease of Access: Avocent DS management software
provides an explorer function that presents your servers
within an intuitive graphical user interface, allowing
you to locate and access your critical resources via
a simple mouse click. With support for custom labels
and icons, it is no longer necessary to recall cryptic
machine names or IP addresses.
- Avocent Telnet Client: Compatible with third-party
SSH and Telnet clients. The CPS appliance comes complete
with an Avocent Java-based Telnet client. The supplied
Telnet client offers file-based session logging, cut
and paste, print screen, session history, macro support
and a wide range of terminal emulations.
- Browser Access: DSWebview combines ease of
Internet access with central security and management.
- Scalable: The CPS appliance architecture
is scalable rather than stackable; there are no restrictions
on the number of DS appliances that can be added to
an installation.
- Non-blocked Access: The CPS appliance architecture
supports simultaneous sessions to all serial ports.
Avocent CPS810 Hardware Features
- Solaris Ready: Hardware break suppression
ensures uninterrupted operation of your Solaris server
even if power is lost to the CPS appliance.
- Break Generation: Hardware break may be intentionally
generated via Telnet or SSH clients.
- Port History: Port history functionality
includes offline buffering, string search and various
modes to save or clear onboard history buffers.
- Direct Port Addressing: Sessions may be established
directly to any CPS appliance port by using SSH to bypass
the CPS appliance command line interface.
- Out-of-band Options:
- Direct terminal attachment
- Dial access using serial applications such as
HyperTerminal
- Dial access using IP-based applications such
as Telnet
- Modem sharing capability via IP forwarding
- Alarms and Alerts:
- MIB-2 Traps
- 10 programmable ‘Cry-for-help'strings per port
- Network Interface:
- 10Base-T/100-BaseTX, autosense
- SSH v2 : with username/password and key-based
authentication methods
- Telnet
- SSL
- RADIUS
- PPP
- SNMP: MIB2 and traps
- TFTP
- BOOTP
- Ping
- ARP
- Serial Interface:
- 8 or 16 RJ45 serial ports
- Hardware and software flow control
- Modem support
- Hardware break suppression
- Unsurpassed surge protection: 15K volts, all
pins
- DB-9 and DB-25 serial adapters
- Rack Optimized:
- 1U form factor
- Two units fit side-by-side within 1U of rack
space
Avocent CPS810 Diagram
Avocent CPS810 Specifications
|
Mechanical |
Height |
|
1.75 in. |
|
|
Width |
|
8.75 in. |
|
|
Depth |
|
8.00 in. |
|
|
Weight |
|
3 lbs |
|
Environmental |
Operating Temp |
|
0C to 40C |
|
|
Storage Temp |
|
|
|
Power |
Operating Voltage |
|
100 - 250 VAC |
|
|
Power Frequency |
|
50 - 60 Hz, 0.5A |
|
|
Input |
|
|
|
Standards
|
Approved Agency
|
|
IEC No. 60950 2nd Ed. A1, A2, A3,
A4, CSA C22.2 No. 950, UL 1950 3rd ed., IEC CB Scheme,
FCC Part 15 Class A, EN 55022: 1998 Class A, EN
610003-2, EN 610003-3; EN 55024: 1998, EN 55082-1
Immunity, 73/23/EEC, EMC Directive 89/336/EEC, CE-Mark
93/68/EEC |
|
Avocent CPS810
Order Details
|
Part Number |
List Price |
| Console Port
Server with vConsole software |
CPS810-AM |
$995
|
| RJ-45 to DB-25
Male adapter, DTE |
210090 |
$15 |
| RJ-45 to DB-25
Female adapter, DTE |
210091 |
$15 |
| RJ-45 to DB-25
Male adapter, DCE |
210092 |
$15 |
| RJ-45 to DB-25
Female adapter, DCE |
210093 |
$15 |
| RJ-45 to DB-9
Male adapter, DTE |
210094 |
$15 |
| RJ-45 to DB-9
Female adapter, DCE |
210095 |
$15 |
| RJ-45 to Cisco
Male adapter for Cisco and Sun Netra console port |
210105 |
$15 |
| RJ-45 to DB-9
Female adapter, DCE |
210120 |
$15 |
| RJ-45 to DB-25
Female adapter, DCE |
210121 |
$15 |
| RJ-45 to DB-9
Male adapter, DTE |
210122 |
$15 |
| RJ-45 to DB-25
Male adapter, DCE |
210123 |
$15 |
| CAT5, RJ-45
to DB-25 Male adapter, DTE |
210124 |
$15 |
| CAT5, RJ-45
to DB-25 Female adapter, DTE |
210125 |
$15 |
CAT5, RJ-45
to RJ45 Cisco Male adapter for Cisco and Sun Netra
console port |
210127 |
$15 |
| CAT5 Serial
Starter Kit: Kit includes all CAT5 adaptors |
750238 |
$45 |
CPS rack mount
kit-holds two CPS units side-by-side within 1U of
rack space |
790200 |
$75 |
| DSView 3 software
- 1 User add-on license |
DSV3-1 |
$795
|
| DSView 3 software
- 5 User add-on license |
DSV3-5 |
$2,995 |
| DSView 3 software
- 1 Spoke Add-on License |
DSV3-SPOKE |
$2,500 |
| DSView 3 Portfolio
B - 1 Hub, 1 Spoke, 5 Users Discontinued |
DSV3-SW |
$4,495 |
| DSView 3 Portfolio
A - 1 Hub, 5 Users Discontinued |
DSV3-SWA |
$2,495 |
DSView 3 software
- Upgrade 1 Hub, 5 Users (Existing DSView 2
customers upgrading to DSView 3) Discontinued |
DSV3UG-SW |
$995
|
| DSView 3 software
- Upgrade 1 Hub, 5 UsersDiscontinued |
DSV3UG-SW |
$995
|
| (Existing DSView
2 customers upgrading to DSView 3) |
|
|
|
Corporate
& Government Discount Pricing is available at 1-800-638-2638
|
| |
|
|
|
Avocent
CPS810 Cables |
Part Number |
List Price |
| 10-foot,
reversing cable (8-wire) |
690226 |
$9 |
| 25-foot,
reversing cable (8-wire) |
690227 |
$12 |
| 75-foot,
reversing cable (8-wire |
690228 |
$17 |
Wiring Starter
Kit (8-wire): Kit Includes: (1) RJ-45 to DB-25 DTE
Male adapter, (1) RJ-45 to DB-25 DCE Male adapter, (1) RJ-45
to DB-25 DCE Female adapter, (1) RJ-45 to DB-9 Male adapter,
(1) RJ-45 to DB-9 Female adapter and (1)10-foot 8-wire
reversing modular cable. |
750122 |
$45 |
|
Corporate
& Government Discount Pricing is available at 1-800-638-2638
|
