APC
AP9470APC has a full line of IP-based environmental monitoring products, including the InfraStruXure. and monitoring devices are IP-based, expandable, and easy to install and use.
|
| |
|
APC AP9470
|
|
The APC AP9470 is a Management platform that enables centralized monitoring, control, trend analysis, and alert history for all of your NetBotz appliances.
APC AP9470 Features - 10/100/1000 BaseT Connection
- Authentication Auto-discovery
- Centralized Alert Repository
- Centralized Management
- Compatible with Add-On Surveillance Software
- Custom mapping
- Data graphing
- Exportable reports
- Fault notification
- Hierarchical device groups
- IDE drive
- Mass Configuration
- Notification groups
- Pentium processor
- Rack mountable
- Scalable architecture
- Single Power Supply
APC AP9470 Specifications | Mechanical |  | Dimensions Weight | | 1.75inH x 21.5inW x 19inD
(4.44cm x 54.6cm x 48cm)
21 lbs. (9.55 kg.) | | | | | | Environmental | Operating
Storage | | 50 - 95 °F (10 - 35 °C), 5-90% Relative Humidity
-31 - 140 °F (-35 - 60 °C), 5-95% Relative Humidity | | | | | | General | On-board RAM & Data Storage | | 2GB/250GB available for data storage | | Communications & Management | Protocols
Network Interface Connections | | DNS,HTTP,HTTPS,SMS,SMTP,SNMP,SSL,TCP/IP
RJ-45 10/100 Base-T,USB |
| | | APC InfraStuXure Central Models | Part Number | | APC InfraStruXure Data Center on Demand | APC InfraStruXure | | AP9485 InfraStruXure Central Enterprise Pilot Pak | AP9485 | | AP9480 InfraStruXure Central Standard Pilot Pak | AP9480 | | AP9470 InfraStruXure Central Standard | AP9470 | | AP9475 InfraStruXure Central Enterprise | AP9475 |
|
| | | | | |
|
|
|
